DESIGN AND MANUFACTURING STANDARDS

Basic Design

ANSI/ASME B 16.34,  API 6D (Full bore), BS1868 (Reduced bore)

Shell Wall Thickness

API 16.34/ API 6D

Face to Face Dimension

ANSI/ASME B16.10/ API 6D

Flange End Dimension

ANSI/ASME B16.5 (2” to 24”) MSS SP-44 (26” & up)

Butt-Weld End Dimension

ANSI/ASME B16.25

Material Grade

Carbon Steel: A216-WCB

Carbon Steel Alloy High-Temp: A217-WC6/ WC9/ WC5

Carbon Steel Alloy Low-Temp: A352-LCB/LCC/LC2/LC3

Stainless Steel: CF8M/CF8C/CF8/CF3/CF3M

Size

2'' - 36''

Class

150Lbs - 300Lbs  - 600Lbs - 900Lbs - 1500Lbs - 2500Lbs

Inspection & Testing

API 598/ API 6D
