DESIGN AND MANUFACTURING STANDARDS

Basic Design

BS 1873 & ANSI/ASME B 16.34

Shell Wall Thickness

BS 1873 & ANSI/ASME B 16.34

Face to Face Dimension

ANSI/ASME B16.10

Flange End Dimension

ANSI/ASMEB16.5

Butt-Weld End Dimension

ANSI/ASME B16.25

Material Grade

Carbon Steel: A216-WCB

Carbon Steel Alloy High-Temp: A217-WC6/ WC9/ WC5

Carbon Steel Alloy Low-Temp: A352-LCB/LCC/LC2/LC3

Stainless Steel: CF8M/CF8C/CF8/CF3/CF3M

Size

2'' - 24''

Class

150Lbs - 300Lbs  - 600Lbs - 900Lbs - 1500Lbs - 2500Lbs

Inspection & Testing

API 598
